TWIN SPINDLE CNC LATHE, OKUMA & HOWA - 2SP 35HG

TWIN SPINDLE CNC LATHE, OKUMA & HOWA - 2SP 35HG

Get a Price/Quote

Product Details:

Product Type Other,
Cutting Speed 3500 RPM
CNC Or Not CNC,
Automatic Grade Automatic,
Control System Other,
Max. Swing Diameter 380 Millimeter (mm)
Weight (kg) 10000 Kilograms (kg)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

TWIN SPINDLE CNC LATHE, OKUMA & HOWA - 2SP 35HG Price And Quantity

Minimum Order Quantity 1 Piece

TWIN SPINDLE CNC LATHE, OKUMA & HOWA - 2SP 35HG Product Specifications

CNC Or Not CNC
Automatic Grade Automatic
Weight (kg) 10000 Kilograms (kg)
Cutting Speed 3500 RPM
Max. Swing Diameter 380 Millimeter (mm)
Control System Other
Product Type Other
Feature Low Noise, Simple Control, High Performance, ECO Friendly, High Efficiency, Stable Performance

TWIN SPINDLE CNC LATHE, OKUMA & HOWA - 2SP 35HG Trade Information

Supply Ability 1 Piece Per Month
Delivery Time 1 Months
Main Export Market(s) Western Europe, Middle East, Central America, Eastern Europe, South America, Asia, North America, Australia, Africa,
Main Domestic Market All India,

Product Description

TWIN-SPINDLE CNC LATHE with NEW SPINDLE LINES

Brand: OKUMA

Model: 2SP - 35 HG

Control: FANUC 18-T

Center distance between spindles: 450 mm
Max. Turning diameter: 380 mm - MANUAL LOAD or with ROBOT

Max. Turning diameter: 160 mm - with OGL LOADER
Max. Turning length: 230 mm

RIGHT and LEFT SPINDLE: Spindle taper: A 2-8
Spindle bore: 82 mm.
Spindle speed: 35 - 3500
Max power available: 18,5 KW.

Longitudinal slide travel - Z : 230 mm. Cross slide travel - X: 225 mm.
Rapid feeds X - Z AXES: 24/30 m / min. Tool stations: 12 + 12

Machine weight: about 9200 Kg.

Floor space: 3.8 x 5.5 m.

ACCESSORIES:
- N.2 SELF-CENTERING DIA. 250 AUTOBLOCK
- CHIP EVACUATOR
- AUTOMATIC DOORS
- TOOL HOLDER KIT
- SELF-CENTERING BLOW
- SPINDLE ORIENTATION
- INTEGRATED PORTAL LOADER WITH PIECES TILTER
- N.1 WAREHOUSE WITH 16 STATIONS ON THE RIGHT SIDE
