CK3B , YANG CNC LATHE
3001.00 - 5000.00 USD ($)/Piece
Product Details:
- Product Type Turning Center,
- CNC Or Not CNC,
- Click to View more
X
CK3B , YANG CNC LATHE Price And Quantity
- 1 Piece
- 3001.00 - 5000.00 USD ($)/Piece
CK3B , YANG CNC LATHE Product Specifications
- Turning Center
- CNC
CK3B , YANG CNC LATHE Trade Information
- 10 Piece Per Day
- 1 Week
Product Description
CNC LATHE
- Make : YANG
- Model : CK - 3B.
- CONTROL : FANUC series 0-T.
- Swing over bed dia : 650 mm.
- Max. machinning dia : 390 x 1220 mm.
- Max. distance between center : 1320 mm.
- Max. longitudinal travel (Z axis) : 1230 mm.
- Z axis feed motor : FANUC AC servo motor 20S 3.5 Kw. Rapid feed of Z axis : 15 m/min.
- Max. cross travel ( X axis ) : 255 mm.
- X axis feed motor : FANUC AC servo motor 10S. 1.8 Kw.
- Rapid feed of X axis : 12 m/min.
- Rapid feed of C axis : 500 rev/min.
- C axis feed motor : FANUC AC servo motor 0S. 0.75 Kw.
- Front bearings bore dia : 120 mm.
- Thru hole dia : 86 mm / 64 mm; 86 mm / 75 mm. (Optional).
- Spindle nose no : ASA A - 2 - 8.
- Taper of spindle bore : 1/20.
- Spindle drive motor : FANUC AC spindle motor 15S 15 Kw / 18.5 Kw. Spindle speed : 30 - 3000 rpm; 35 - 3500 rpm.
- Diameter of tailstock spindle : 85 mm.
- Vertical octagonal turret.
- Height from floor to spindle center line : 1120 mm.
- Height from bed to spindle center line : 330 mm.
- General dimension : 4850 x 2500 x 2550 mm.
- Total weight of the machine : 7500 Kg.
