ML 25A , YANG CNC LATHE
3001.00 - 5000.00 USD ($)/Piece
Product Details:
- Product Type Turning Center,
- CNC Or Not CNC,
- Click to View more
X
ML 25A , YANG CNC LATHE Price And Quantity
- 1 Piece
- 3001.00 - 5000.00 USD ($)/Piece
ML 25A , YANG CNC LATHE Product Specifications
- Turning Center
- CNC
ML 25A , YANG CNC LATHE Trade Information
- 10 Piece Per Day
- 1 Week
Product Description
CNC LATHE
- Make : YANG.
- Model : ML 25A.
- CONTROL : FANUC series 0-T.
- Swing over bed dia : 550 mm.
- Chuck diameter : 280 x 520 mm.
- Swing over saddle : 350 mm.
- Max. distance between center : 600 mm. Max. longitudinal travel : 520 mm.
- Z axis feed motor : FANUC AC servo motor 10S 1.8 Kw. Rapid feed of Z axis : 12 m/min.
- Max. cross travel : 216 mm.
- X axis feed motor : FANUC AC servo motor 5S. 0.9 Kw. Rapid feed of X axis : 20 m/min.
- Front bearings bore dia : 110 mm.
- Thru hole dia : 77 mm.
- Taper of spindle bore : MT NO. 7.
- Spindle drive motor : FANUC AC spindle motor 8S 7.5 Kw / 11 Kw. Spindel speed : 45 - 4500 rpm.
- Diameter of tailstock spindle : 85 mm.
- Vertical octagonal turret.
- Height from bed to spindle center line : 295 mm. General dimension : 4000 x 2000 x 2220 mm. Total weight of the machine : 5000 Kg.
