KNAPP Rack Cutting Milling Machine

Owing to the Dedication of Our Diligent Professionals, We Have Earned a Reputed Name in Offering the Finest Quality Assortment of Used KNAPP Rack Cutting Milling Machine. Low Maintenance, Robust Construction, High Material Strength and Easy to Install Are Salient Attributes of Offered Machine. Our Quality Experts Strictly Examine This Machine on Well-defined Quality Parameters, in Order to Offer Flawless Range at the Customers End. We Offer This Used Rack Milling Machine in Various Specifications and Models So as to Satisfy the Demands of Our Clients.

Rack Milling Machine

• Make : Knapp.
• Model : Uzfm.
• Max Pitch : Modul 8
• Max Pitch Cast Iron : Module 10
• Max Length : 1750mm
• Size of Table With Water Channel : 2100 X 460mm
• Size of Table : 1850 X 250mm
• Horizontal Movement of Milling Head : 260mm
• Min./max. Height Between Table & Spindle Centre : 136mm/410mm
• Range of Variable Feeds : 0-300 Mm/min
• Rapid Traverse : 3 M/min
• Range of Milling Speeds : 29-178 Rpm
• Swivel of Spindle Head (Left) Relief Milled : 45 Degree
• Swivel of Spindle Head (Right) : 30 Degree
• Swivel of Saddle Either Side (Spiral Gearing) : 30 Degree
• Dia of Arbor Inside Support : 25-40mm
• Max. With of Cutter : 100mm
• Dia of Arbor Outside : 22-32mm
• Max Capacity Width of Cutter Outside : 50mm
• Min Dia of Cutter : 105mm
• Max Dia of Cutter : 165mm
• Indexing Spindle Pitch : Module : 4=12,5-66mm
• Weight of Machine : 3500kg
