JONES SHIPMAN Cylindrical Grinder Machine

Owing to Our Expertise in This Domain, We Are Occupied in Providing Top Class Used JONES SHIPMAN Cylindrical Grinder Machine. Robust Construction, Easy to Install, Low Maintenance and Excellent Working Are Different Qualities of Offered Machine. The Blades of These Grinder Machines Are Very Sharp and Require Less Maintenance. Our Offered Product Is Well-fitted and Ensures Greater Durability With Flawless and Speedy Results. This  Used Cylindrical Grinder Machine Is Light in Weight and Can Easily Be Accommodated.

Universal Internal and External Cylindrical Grinder

• Make : Jones Shipman.
• Model : 1310.
• Max Diameter With New Wheel : 200 Mm.
• Max Grinding Length Between Centre : 460 Mm.
• Adjustment of Table, Included Angle : 20°.
• Vertical Traverse of Wheeled : 158 Mm.
• Wheelhead Centre to Table Min/max : 111-270 Mm.
• Wheelhead Motor : 1.1 Kw.
• Wheel Size : 230 Mm.
• Speed of External Grinding Wheel : 2100/2550 Rpm.
• Work Head Speeds (6) : 30-415 Rpm.
• Approximate Weight : 1800 Kg.
